DUCTED AIR CONDITIONING SYSTEM OVERVIEW

Once your system is installed you may also refer to the operating manual for more information on both operating and maintaining your system.

DESIGN CONDITIONS

To achieve maximum performance of the equipment selected, the following should be considered:

Ceilings are insulated with R2.5 (added – product value) or R3.5 (total system). All windows are shaded with either blinds, drapes, external shutters or window tinting. External doors and windows are closed during operation. The air conditioning equipment selected should maintain a comfortable room temperature of 24°C DB* + or - 2°C and a relative humidity of 55% + or – 5% when the outdoor design conditions are at 32°C DB and 25°C WB **

* DB – Dry Bulb ** WB – Wet Bulb
